Description
CyberPower VP1000ELCD offers home and office users a reliable battery backup and safeguards office PCs and other electronic devices from surges, spikes, brownouts and other power incidents. Designed with GreenPower UPS™ Technology to improve operating efficiency and to minimize energy consumption, users can enjoy significant energy cost savings over conventional UPS systems. The UPS provides Automatic Voltage Regulation (AVR) to maintain safe voltage for connected equipment.
The UPS provides multifunctional LCD readout to display clear power and battery conditions. The product features data line protection with high-speed transmission to safeguard phones, network and communication equipment against surge/spike as well as supply 1Gbps speed to transmit data. The UPS is also compatible with PowerPanel® Power Management Software to achieve real-time monitoring and configuration.
Features
- Works adequately in situations where the supply is prone to sags and surges
- Keep your sensitive devices powered with a backup of up to 1 minute at full load
Specifications :
Controls/Indicators
|
Status Indicators |
LCD Information Display:
LED Indicators:
|
Miscellaneous
|
Environmentally Friendly |
Yes |
Interfaces/Ports
|
Network (RJ-45) |
Yes |
|
Serial Port |
Yes |
|
USB (HID Compliant) Port |
Yes |
Management
|
Alarm |
Low Battery |
|
Battery Mode |
|
|
UPS Fault |
|
|
Overload |
Technical Information
|
Application/Usage |
Surveillance System |
|
Mission Critical Equipment |
|
|
Home Theatre |
|
|
Home |
|
|
Computer |
|
|
Workstation |
|
|
Telecommunication |
|
|
Multimedia Device |
|
|
Storage Device |
|
|
Security System |
|
|
POS Terminal |
|
|
Office |
|
|
Network Device |
|
|
Dataline Protection |
RJ-45 |
|
RJ-11 |
|
|
Overload Protection |
Yes |
|
Plug/Connector Type |
IEC 60320 C14 |
|
Phase |
Single Phase |
|
Receptacle Type |
AU |
|
EMI/RFI Noise Filter |
Yes |
|
AVR |
Yes |
|
Energy Saving |
GreenPower UPS Bypass Technology |
|
Number of Battery & Surge Outlets |
3 |
|
Transfer Time |
4 ms |
|
Receptacle Detail |
3 x AU |
Battery Information
|
Battery Chemistry |
Lead Acid |
|
Backup/Run Time (Half Load) |
9 Minute |
|
Backup/Run Time (Full Load) |
1 Minute |
|
Replaceable Battery |
No |
|
Typical Battery Recharge Time |
8 Hour |
Environmental Conditions
|
Thermal Dissipation |
23.90 BTU/h |
|
Maximum Operating Temperature |
40°C |
|
Maximum Operating Elevation |
3.05 km |
|
Maximum Storage Elevation |
3.05 km |
|
Sound Emission (A-Weighted) |
40 dB(A) |
Physical Characteristics
|
Weight (Approximate) |
6.23 kg |
|
Form Factor |
Tower |
|
Height |
226.1 mm |
|
Width |
99.1 mm |
|
Depth |
259.1 mm |
General Information
|
Product Type |
Line-interactive UPS |
|
Manufacturer Website Address |
|
|
Manufacturer |
CyberPower Systems, Inc |
|
Product Model |
VP1000ELCD |
|
Product Name |
Value Pro VP1000ELCD 1000VA Tower UPS |
|
Product Line |
Value Pro |
|
Brand Name |
CyberPower |
Power Description
|
Input Voltage |
230 V AC |
|
Output Voltage |
230 V AC |
|
Surge Energy Rating |
450 J |
|
Waveform Type |
Simulated Sine Wave |
|
Input Voltage Range |
167 V AC - 295 V AC |
|
Output Frequency |
60 Hz |
|
Input Frequency |
60 Hz |
