Accessories : Wristband Rfid Transponder


$72.00
(Inc GST)
WB06
+

Description

Making a big splash at waterparks across the nation, the PDC Smart® Rewearable Wristband is a waterproof, 100% silicone wristband embedded with an RFID transponder.

Attachments

WRISTBAND RFID TRANSPONDER Brochure (Datasheet_WB-06.pdf., 288 Kb) [Download]

Specifications



Functionality

Read Only

Memory (bits)

64

Memory Pages

1

Modulation

FSK 134.2 kHz / 123.2 kHz

Transmission Principle

Half Duplex (HDX)

Power Source

Powered from the reader signal

Typical reading range

approx 7cm

Operating Temperature

-25° to +70°C

Storage Temperature

-40° to +85°C

Case Material

Glass

Protection Class

Hermetically sealed

EMC

Programmed code not affected by normal electromagnetic Interference or X-rays

Dimensions

φ3.85 mm ± 0.05 mm x 23.1 mm ± 0.5 mm

Weight

0.6g

Operating Frequency

134.2kHz
